GTE Industrieelektronik Impact Force Test Device KMG-2000-G

two distance extension arms 300 / 500 mm, for force testing device KMG, includes transport case Description: The KMG Extension Set by GTE Industrieelektronik was specifically designed as accessory set for the KMG. It is easily connected to the KMG and allows for simple impact force measurement at the most important measurement points on automatic pedestrian doors as well as vertically and horizontally moving doors.   Properties: Transport case for KMG-Lite/ KMG-T as well as all accessory parts Screw-on distance arms for 300 and 500mm extensions of the KMG Lite Robust tripod Protocol block for documentation of the results

Test device for the annual testing of impact forces on doors and gates as required by ASR 1.7, measurement range 25N to 2000N Description: The force measurement device KMG-T by GTE Industrieelektronik was specifically designed for the annual impact force testing on doors and gates. It is the answer of GTE to ASR A 1.7, which is in force since 2009 and requires the annual check-up of the impact forces on all doors in industrial/ commercial setting. The KMG-T fulfils the requirements of DIN EN 12445, DIN 18650 and EN 16005 and allows for an automatic evaluation of the test results according to DIN EN 12453 appendix A. The KMG-T is the successor model to the popular and widely used KMG-Lite. With the KMG-T, the force measuring device now has Bluetooth functionality as standard for transmitting the measured values. The internal lithium-ion battery ensures sufficient power supply even for longer periods of use and the large illuminated display makes the KMG-T easy to operate. Properties: Stand-alone test device Bluetooth functionality as standard Easy to use Ideally suited for annual check-ups according to ASR A 1.7 Large display with illuminated LCD display Mechanical overload protection  Internal lithium-ion battery Automatic evaluation of the standardised parameters Fdyn, tdyn, Fend Standard-compliant force evaluation Extended measurement memory USB-C connection Automatic measurement readiness for measurement series Note: The KMG-VISION software and KMG-VISION.cloud app are currently still in the manufacturer's beta test phase. Once the test phase has been successfully completed, these solutions will be made available to all customers.

two distance extension arms 300 / 500 mm, for force testing device KMG, includes transport case Description: The KMG Extension Set by GTE Industrieelektronik was specifically designed as accessory set for the KMG. It is easily connected to the KMG and allows for simple impact force measurement at the most important measurement points on automatic pedestrian doors as well as vertically and horizontally moving doors.   Properties: Transport case for KMG-Lite/ KMG-T as well as all accessory parts Screw-on distance arms for 300 and 500mm extensions of the KMG Lite Robust tripod Protocol block for documentation of the results

Test device for the annual testing of impact forces on doors and gates as required by ASR 1.7, measurement range 25N to 2000N Description: The force measurement device KMG-T by GTE Industrieelektronik was specifically designed for the annual impact force testing on doors and gates. It is the answer of GTE to ASR A 1.7, which is in force since 2009 and requires the annual check-up of the impact forces on all doors in industrial/ commercial setting. The KMG-T fulfils the requirements of DIN EN 12445, DIN 18650 and EN 16005 and allows for an automatic evaluation of the test results according to DIN EN 12453 appendix A. The KMG-T is the successor model to the popular and widely used KMG-Lite. With the KMG-T, the force measuring device now has Bluetooth functionality as standard for transmitting the measured values. The internal lithium-ion battery ensures sufficient power supply even for longer periods of use and the large illuminated display makes the KMG-T easy to operate. Properties: Stand-alone test device Bluetooth functionality as standard Easy to use Ideally suited for annual check-ups according to ASR A 1.7 Large display with illuminated LCD display Mechanical overload protection  Internal lithium-ion battery Automatic evaluation of the standardised parameters Fdyn, tdyn, Fend Standard-compliant force evaluation Extended measurement memory USB-C connection Automatic measurement readiness for measurement series Note: The KMG-VISION software and KMG-VISION.cloud app are currently still in the manufacturer's beta test phase. Once the test phase has been successfully completed, these solutions will be made available to all customers.
