GfA Elektromaten Door Control TS 971 with CEE 1N~230V (3 pole)

Cable set for optical sensing edges OSE, includes coil cord 4x0,25 mm², cable ends 2,0m/ 0,35m, max. extension length 3,5m, with junction box and connection PCBDescription:The cable set for optical sensing edges consists of:- Pluggable 4-core coil cord, straight cable ends 2,0m/ 0,35m length, can be extended to a max. length of 3,5m - pre-assembled plug for connecting to GfA Elektromaten door control units- IP65 junction box with plug-in connector for OSE transmitter / receiver as well as pass-door and slack-door switches.

Replacement PCB for TS971 by GfA Elektromaten, delivery includes cover and keypad, universal replacement part for all versions/ covercolours of TS971Description:The Circuit Board TS971 by GfA Elektromaten is an original replacement parts for replacing defect electronics of the door control unit TS971. The TS971 replacement board can universally be used for all manufacturing years and models/ housing colours of the TS971.The replacement board comes as a pre-assembled unit including cover and push-buttons, as shown on the pictures above. Your benefits at doorautomation24:free technical support by phone100% original parts by GfA ElektromatenFast order processing and shipping*Shipping fee within EU, to Switzerland and Norway only 9,90 EUR*For orders and payments received before 14:00 from Monday through Friday we usually dispatch your goods on the same working day.

Midi radio transmitter SKX1LC by GfA Elektromaten, 1-channel, 434 MHz, coded via dip-switch, includes 12V battery, status LEDDescription:GfA Elektromaten SKX1LC Midi radio transmitter.Technical characteristics:434 MHzcoded via dip-switchincludes 12V batteryLED status display

The VTX2 remote control from doorautomation24 combines modern design and reliable performance in a compact format. Equipped with a robust plastic housing, the remote control offers excellent functionality and is the perfect choice for the control of various devices. The high-quality workmanship and strong radio parameters of the VTX ensure reliable and convenient use. The remote controls of the VTX series are compatible with the radio receiver VRX150 from doorautomation24 and the integrated radio receiver of the door control unit TS971 from GfA Elektromaten. The integration into the existing door control unit TS971 is simple and is explained step by step in the document available under ‘Download’. Important features: Design: Robust plastic housing for long-lasting use Compatibility: Fully compatible with the VRX150 receiver from doorautomation24 and the TS971 from GfA Elektromaten Range, coverage: Stable radio range of up to 150 metres Security: KeeLoq® rolling code for high security with 4,294,967,296 possible combinations User-friendly: powered by 2 standard CR2016 batteries (included)   Important information for use with the TS971 from GfA Elektromaten: To teach the remote control to the door control unit, the remote control must be programmed using the corresponding parameter of the door control unit. To do this, the installer must have access to the control unit programming.

Bottom section for GfA Elektromaten control units TS959, TS970 and TS971, for installation of the TS board

Separate connection kit for GfA Elektromaten door controls type TS, for direct wiring

Cover set for GfA Elektromaten control units TS959, TS970 and TS971, set consists of small and large cover part

Separate connection kit for GfA Elektromaten door controls type TS, with mains switch/ isolator 1N~230V

Separate connection kit for GfA Elektromaten door controls type TS, with mains switch/ isolator 3N~400V

Replacement PCB for TS971 by GfA Elektromaten, delivery includes cover and keypad, universal replacement part for all versions/ covercolours of TS971Description:The Circuit Board TS971 by GfA Elektromaten is an original replacement parts for replacing defect electronics of the door control unit TS971. The TS971 replacement board can universally be used for all manufacturing years and models/ housing colours of the TS971.The replacement board comes as a pre-assembled unit including cover and push-buttons, as shown on the pictures above. Your benefits at doorautomation24:free technical support by phone100% original parts by GfA ElektromatenFast order processing and shipping*Shipping fee within EU, to Switzerland and Norway only 9,90 EUR*For orders and payments received before 14:00 from Monday through Friday we usually dispatch your goods on the same working day.

Door control unit for GfA Elektromaten drives with digital or mechanical limit switch, constant pressure to close operation only, with 0,7m connection cable and CEE-plugDescription:The Door Control Unit GfA Elektromaten TS959 is a deadman door control for GfA Elektromaten drives with digital limit switch DES or mechanical limit switch NES.Features:Protection class IP54 with CEE plug or IP65 with direct connectionintegrated push button for UP-STOP-CLOSE commandsControl parameter setting via rotary selectors with digital displayIndependently programmable relay contact for use with traffic lights or ramp releases for exampleOperating modes: Deadman CLOSED/OPEN, Deadman CLOSED/ self-hold OPEN

Door control unit for GfA Elektromaten drives with digital or mechanical limit switch, automatic or constant pressure to close operation, with 0,7m cable and CEE-plugDescription:The door control unit TS 970 by GfA Elektromaten is an automatic control panel for use with GfA Elektromaten drives with digital (DES) or mechanical (NES) limit switch system.Properties:Protection class IP54Integrated push button for UP-STOP-CLOSE commandsParameter setting via selector switch with digital displayIndependent, programmable relay contact, e.g. for red-green traffic-lightsOperating modes: hold-to-run mode or self-hold/ automatic modeAutomatic detection of safety edge type (Optical edge FRABA VITECTOR, resistive edge 8k2 or NC-contact type 1k2 with testing)Automatic timer-to-closeAdjustable intermediate open position, e.g. half open, venting positionDue to the pre-assembled, pluggable motor cable, the TS 970 can easily be connected to the drive. A faulty wiring is hereby avoided, thus minimizing installation errors and time. The connection cable can be wired into the control panel housing from either top or bottom. In addition tot he motor cable, the TS 970 can work with a multitude of additional inputs, e.g. rope-switches, photo eyes, sensing edges and many more.The TS970 by GfA includes most standard features of a modern door control panel and can therefore be used to operate most industrial doors. For more demanding applications, GfA Elektromaten offers the control panel types TS971 or TS981.

Door control unit for GfA Elektromaten drives with digital or mechanical limit switch, automatic or constant pressure to close operation, in stainless steel housing for applications with high requirements for hygiene and corrosion protection, version AISI 304L (V2A)Description:The GfA Elektromaten TS 971 door control unit is an automatic controller for GfA Elektromaten drives with digital (DES) or mechanical limit switches (NES). The TS971 control unit comes, as standard, with an integrated radio receiver for 434 MHz radio products from various manufacturers and a radio reception module for the WSD-type safety devices. Unfortunately, the use of WSD-systems is not possible with TS971 control units in stainless-steel enclosures. The use of the integrated 434 MHz radio system is only possible through the application of external antennae (our Art. Nr. TA0400064).Properties:Protection class IP66Integrated push button for UP-STOP-CLOSE commandsControl parameter setting via rotary selector switch with digital displayIntegrated radio transmissions system for WSD safety devicesIntegrated radio receiver compatible with various 434 MHz manufacturer systems.Two independent programmable relay contacts useful e.g. for traffic lights or ramp releases etc.Operating modes: constant-pressure-to-close, or self-retaining / automatic opening and closingAutomatic recognition of the sensing edge type (optical sensing edge FRABA VIECTOR, resistant sensing edges 8k2 or open-principle 1k2 with testing)Adjustable automatic timer-to-closeAdjustable intermediate opening e.g. half-open, ventilation position etc.Automatic ground adjustment (on drives with digital limit switch DES).As the pluggable cables are pre-configured, the TS971 is easily connected to the drive, avoiding faulty connection problems and clearly reducing wiring times. The cable can be connected to the control box from above or below.Besides the pluggable cables, many other accessories such as rope-pull switches, photo-eyes, sensing edges, etc., are available and can be connected to the door control unit.Because the "wireless" function on the GfA TS971 is already integrated, the controller is factory-equipped with a radio receiver for wireless hand-held transmitters from various manufacturers with a radio frequency of 434 MHz. Thus, it is not necessary to connect an additional receiver to operate via remote control. The controller is also compatible with the GfA Elektromaten radio transmission system WSD. This system is especially adapted for safety devices and enables wireless monitoring of common safety edge systems, as well as pass-door and slack-rope switches.Accordingly, wear-prone spiral cables can be disposed of. Of course, with the TS971, it is also possible connect the electronics on the door side with the spiral cable instead of the WSD system.Through this comprehensive function packet, the TS971 is also suitable for complex applications for the operation of industrial doors. For more simple standard applications, the GfA Elektromaten door controller type GfA TS970 is also available.

Door control unit for GfA Elektromaten drives with digital or mechanical limit switch, automatic or constant pressure to close operation, in stainless steel housing for applications with high requirements for hygiene and corrosion protection, version AISI 316L (V4A)Description:The GfA Elektromaten TS 971 door control unit is an automatic controller for GfA Elektromaten drives with digital (DES) or mechanical limit switches (NES). The TS971 control unit comes, as standard, with an integrated radio receiver for 434 MHz radio products from various manufacturers and a radio reception module for the WSD-type safety devices. Unfortunately, the use of WSD-systems is not possible with TS971 control units in stainless-steel enclosures. The use of the integrated 434 MHz radio system is only possible through the application of external antennae (our Art. Nr. TA0400064).Properties:Protection class IP66Integrated push button for UP-STOP-CLOSE commandsControl parameter setting via rotary selector switch with digital displayIntegrated radio transmissions system for WSD safety devicesIntegrated radio receiver compatible with various 434 MHz manufacturer systems.Two independent programmable relay contacts useful e.g. for traffic lights or ramp releases etc.Operating modes: constant-pressure-to-close, or self-retaining / automatic opening and closingAutomatic recognition of the sensing edge type (optical sensing edge FRABA VIECTOR, resistant sensing edges 8k2 or open-principle 1k2 with testing)Adjustable automatic timer-to-closeAdjustable intermediate opening e.g. half-open, ventilation position etc.Automatic ground adjustment (on drives with digital limit switch DES).As the pluggable cables are pre-configured, the TS971 is easily connected to the drive, avoiding faulty connection problems and clearly reducing wiring times. The cable can be connected to the control box from above or below.Besides the pluggable cables, many other accessories such as rope-pull switches, photo-eyes, sensing edges, etc., are available and can be connected to the door control unit.Because the "wireless" function on the GfA TS971 is already integrated, the controller is factory-equipped with a radio receiver for wireless hand-held transmitters from various manufacturers with a radio frequency of 434 MHz. Thus, it is not necessary to connect an additional receiver to operate via remote control. The controller is also compatible with the GfA Elektromaten radio transmission system WSD. This system is especially adapted for safety devices and enables wireless monitoring of common safety edge systems, as well as pass-door and slack-rope switches.Accordingly, wear-prone spiral cables can be disposed of. Of course, with the TS971, it is also possible connect the electronics on the door side with the spiral cable instead of the WSD system.Through this comprehensive function packet, the TS971 is also suitable for complex applications for the operation of industrial doors. For more simple standard applications, the GfA Elektromaten door controller type GfA TS970 is also available.

Door control unit for GfA Elektromaten drives with digital or mechanical limit switch, automatic or constant pressure to close operation, with integrated radio system, in XL plastic housing, with connection kit for hardwiringDescription:The door control unit TS 971 by GfA Elektromaten is an automatic control panel for use with GfA Elektromaten drives with digital (DES) or mechanical (NES) limit switch system. The TS 971 control panel comes with an integrated radio receiver for 434 MHz radio products of different manufacturers. In addition the TS 971 has an integrated receiver, that can be used for the wireless transmission of the door safety edge in combination with the optional WSD module.Properties:Protection class IP54 with CEE plug or IP65 for direct wiringIntegrated push button for UP-STOP-CLOSE commandsIntegrated radio receiver for 434 MHz wireless productsParameter setting via selector switch with digital displayTwo independent, programmable relay contacts, e.g. for red-green traffic-lightsOperating modes: hold-to-run mode or self-hold/ automatic modeAutomatic detection of safety edge type (Optical edge FRABA VITECTOR, resistive edge 8k2 or NC-contact type 1k2 with testing)Automatic timer-to-closeAdjustable intermediate open position, e.g. half open, venting positionAutomatic ground adjustment (only DES) to compensate for rope-stretch or subsequent change in ground heightDue to the pre-assembled, pluggable motor cable, the TS 971 can easily be connected to the drive. Faulty wiring is hereby avoided, thus minimizing installation errors and time. The connection cable can be wired into the control panel housing from either top or bottom. In addition to the motor cable, the TS 971 can work with a multitude of additional inputs, e.g. rope-switches, photo eyes, sensing edges and many more.The TS 971 by GfA Elektromaten comes with the function "radio/ wireless" already integrated, the control panel has an integrated receiver for remotes of different manufacturers using a frequency of 434 MHz. An additional radio receiver is not needed. In addition the wireless sensing edge transmission system WSD is already integrated on the control panel side. The WSD system is a wireless transmission system for sensing edges and allows monitoring and transmission of the most common sensing edge types, as well as pedestrian door and rope tension switches. The use of a coil cord is no longer needed. Of course the TS971 also allows for connection with a coil cord.The TS971 has comfort functions and allows installation in more demanding applications. For standard-applications GfA Elektromaten offers the panel type TS970.

Door control unit for GfA Elektromaten drives with digital or mechanical limit switch, automatic or constant pressure to close operation, with integrated radio system, in XL plastic housing, with mains switch 3N~400V built into the lidDescription:The door control unit TS 971 by GfA Elektromaten is an automatic control panel for use with GfA Elektromaten drives with digital (DES) or mechanical (NES) limit switch system. The TS 971 control panel comes with an integrated radio receiver for 434 MHz radio products from different manufacturers. In addition the TS 971 has an integrated receiver, that can be used for the wireless transmission of the door safety edge in combination with the optional WSD module.Properties:Protection class IP54 with CEE plug or IP65 for direct wiringIntegrated push button for UP-STOP-CLOSE commandsIntegrated radio receiver for 434 MHz wireless productsParameter setting via selector switch with digital displayTwo independent, programmable relay contacts, e.g. for red-green traffic-lightsOperating modes: hold-to-run mode or self-hold/ automatic modeAutomatic detection of safety edge type (Optical edge FRABA VITECTOR, resistive edge 8k2 or NC-contact type 1k2 with testing)Automatic timer-to-closeAdjustable intermediate open position, e.g. half open, venting positionAutomatic ground adjustment (only DES) to compensate for rope-stretch or subsequent change in ground heightDue to the pre-assembled, pluggable motor cable, the TS 971 can easily be connected to the drive. Faulty wiring is hereby avoided, thus minimizing installation errors and time. The connection cable can be wired into the control panel housing from either top or bottom. In addition to the motor cable, the TS 971 can work with a multitude of additional inputs, e.g. rope-switches, photo eyes, sensing edges and many more.The TS 971 by GfA Elektromaten comes with the function "radio/ wireless" already integrated, the control panel has an integrated receiver for transmitters (remotes) from different manufacturers using a frequency of 434 MHz. An additional radio receiver is not needed. In addition the wireless sensing edge transmission system WSD is already integrated on the control panel side. The WSD system is a wireless transmission system for sensing edges and allows monitoring and transmission of the most common sensing edge types, as well as pedestrian door and rope tension switches. The use of a coil cord is no longer needed. Of course the TS971 also allows for connection with a coil cord.The TS971 has comfort functions and allows installation in more demanding applications. For standard-applications GfA Elektromaten offers the panel type TS970.
