Bircher LBGate R18 Reflective Photo Eye max. Range 9m
€89.00
delivery time: 3-5 working days
Product information "Bircher LBGate R18 Reflective Photo Eye max. Range 9m"
reflective photo eye, max. range 9m, supply voltage 24 ... 240 V AC/ 12 ... 240 V DC, signal output: changeover relay, IP67 rated, 2m connection cable
Description:
The universal reflective light barrier LBGate R18 from Bircher for contactless protection of the openings on industrial doors. The LBGate R18 photoelectric sensor operates in an extremely wide voltage supply range and through the implementation of the output signal as a changeover relay (normally closed and normally open) it is compatible with most door control systems.
The photo eye works with a visible red light (630nm wavelength) and has a built-in polarisation filter. Through this, the photo eye is completely impervious to outside lights and easy to instal.
- Max. range up to 9m
- Power supply range AC 24 to 240V, DC 12 to 220V
- 2m connection cable
- Relay output (changeover)
| Cable Length: | 2.0 m |
|---|---|
| Connection Type: | Cable, w/o plug |
| Material: | PC |
| Max. Operating Temperature: | +55 °C |
| Min. Operating Temperature: | -25 °C |
| Output: | 1x Relay |
| Protection Class: | IP 67 |
| Range: | 9 m |
| Supply Voltage: | AC 24-240 V, DC 12-240 V |
