Marantec Digital 572 Remote 2-Channel 868 MHz bi.linked

Marantec Digital 564 4-channel bi-linked remote control, 868 MHz frequency, incl. battery Product details: The Marantec Digital 564 remote with 868 MHz bi-linked technology offers a simple and reliable solution for the control of Marantec and compatible third-party operators. The remote has four radio channels that you can use to operate up to four gate operators. Contents:- 1 x Marantec Digital 564 remote 868 MHz bi-linked- 1 x batteryThanks to its compact design, the Marantec Digital 564 fits comfortably on a key ring or in a car, making it particularly practical to use. It is easy to programme and connect to different drives.

Module receiver with 200 memory locations, bidirectional, 868 MHz bi.linked. For Comfort 260 (accu/speed), 270 (speed), 280, 360, 370, 380 and 390 (plus) from control box R10. For Control x.52, CS 265 and VTA.   Contents: Module receiver Features: IMPULS function Generous memory for up to 200 buttons Can be plugged directly into the control Compact size

10-channel Maxi remote, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Remote with batteryWall bracketMounting hardwareFeatures:10 function keys for free assignmentSignalling via red LEDHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

999-channel multi-remote, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a compatible bi.linked receiver). Contents:Remote with batteryFeatures:999 channels for free assignmentOperation by entering the channel number and pressing the Enter key (IMPULS)Display via LCD screenHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

999-channel multi-remote with directional buttons, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with the appropriate bi.linked receiver). Contents:Remote with batteryFeatures:999 channels for free assignmentOperation by entering the channel number and pressing a direction key (UP-Stop-DOWN)Display via LCD screenHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

4-channel radio code keypad with 3 permanent PINs, one temporary PIN and a light button, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Radio code keypad with 2 batteriesMounting materialsFeatures:Operation via entry of a 4-digit PIN3 freely selectable user PINs for assigning functions1 freely selectable temporary user PIN (usable 3 times)1 changeable master PIN for administration1 function key for free assignmentSignalling via red LEDHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code method)

4-channel wireless code keypad with 3 permanent PINs, one temporary PIN, a light button and a protective cover, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Radio code keypad with 2 batteriesMounting materialsFeatures:Operation via entry of a 4-digit PIN3 freely selectable user PINs for customisable function assignment1 freely selectable temporary user PIN (usable 3 times)1 changeable master PIN for administrationSignalling via red LEDSliding cover protects the keypad from dirtHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code method)

4-channel wireless code keypad with 3 permanent PINs, one temporary PIN, a light button and a protective cover, unidirectional, 868 MHz bi.linked, neutral finish. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Radio code keypad with 2 batteriesMounting materialsFeatures:Operation via entry of a 4-digit PIN3 freely selectable user PINs for customisable function assignment1 freely selectable temporary user PIN (usable 3 times)1 changeable master PIN for administrationSignalling via red LEDSliding cover protects the keypad from dirtHigh security thanks to 128-bit AES-encrypted wireless transmission and constantly changing wireless code (rolling code method)

4-channel wireless indoor push-button switch with light and ventilation buttons, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Wireless indoor push-button switch with 2 batteriesMounting materialsFeatures:2 function buttons for free assignment1 button for actuations of the drive lighting ON/OFF1 button for operating the ventilation positionSignalling via red LEDHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

4-channel wireless indoor push-button switch with light and ventilation buttons, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Wireless indoor push-button switch with 2 batteriesMounting materialsFeatures:2 function buttons for free assignment1 button for actuations of the drive lighting ON/OFF1 button for operating the ventilation positionSignalling via red LEDHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

4-channel mini remote, unidirectional, 868 MHz bi.linked, neutral version. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Remote with batteryWall bracket with mounting materialsFeatures:4 function buttons for free assignmentSignalling via red LEDEyelet for a bracket / mount to attach to a key ring or lanyardHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

2-channel micro remote, unidirectional, 868 MHz bi.linked, neutral version. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Remote with batteryFeatures:2 function buttons for free assignmentSignalling via red LEDEyelet for a bracket / mount to attach to a key ring or lanyardHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

3-channel mini remote with status query, bidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Remote with batteryWall bracket with mounting materialsFeatures:3 function buttons for free assignment1 button for checking the gate positionAutomatic indication of direction of travel when button is pressedMulti-coloured LED indicationBracket / mount for attaching to a key ring or lanyardHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code system)

4-channel flush-mounted transmitter, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products (in conjunction with a suitable bi.linked receiver). Contents:Flush-mounted transmitter with batteryConnection cable, 90 mmFeatures:4 potential-free inputs for connecting e.g. push-buttons – wired push-buttons thus become wireless push-buttonsHigh security thanks to 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code method)

Module receiver with 200 memory slots and magnetic base antenna with 5 m cable, bidirectional, 868 MHz bi.linked. For Comfort 260 (accu/speed), 270 (speed), 280, 360, 370, 380 and 390 (plus) from Controlbox R10. For Control x.52, x.82, CS 255 AC and VTA. Contents:Module antenna with connection for magnetic base antennaMagnetic base antenna with connection cable, 5,000 mmMounting bracketMounting hardware

Module receiver with 200 memory slots and 1 open-collector output, 24 V, unidirectional, 868 MHz bi.linked. For CS 320. For third-party products (in conjunction with the supplied connection cable). Scope of delivery:Universal receiverConnection cable, 300 mmFeatures:1 channel for free assignment1 potential-free relay contact for switching an electrical device, e.g. pulse input of a door control unitPULSE functionGenerous memory capacity for up to 200 buttonsCompact size

2-channel universal receiver with 100 memory slots per relay, 24 V, IP65, unidirectional, 868 MHz bi.linked. For all Marantec controls and third-party products. Scope of delivery:Universal receiverMounting hardwareFeatures:Weather-resistant housing2 channels for free assignment2 potential-free relay contacts for switching electrical devices, e.g. pulse input of a door control unitPulse or ON/OFF function separately adjustable per channelGenerous memory capacity for up to 100 buttons per channelConnection via conventional wiring for external push-buttons to directly switch each relay

1-channel socket receiver with 200 memory slots, Schuko type F, unidirectional, 868 MHz bi.linked. For all Marantec control units and third-party products. Contents:Socket receiver with Schuko plug and socket type FConnection cable, 1,500 mmFeatures:1 channel for free assignment1 potential-free relay contact for switching an electrical device, e.g. pulse input of a door control unitPULSE functionGenerous memory capacity for up to 200 buttonsPower supply via the drive’s mains socket without blocking itEasy conversion of third-party drives to Marantec remote transmitters or to change the radio frequency

1-channel flush-mounted receiver with 200 memory slots and a live relay, 230 V, unidirectional, 868 MHz bi.linked. For all Marantec controls and third-party products. Scope of delivery:Flush-mounted receiverFeatures:1 channel for free assignment1 live relay contact for directly switching an electrical device, e.g. an outdoor lightON/OFF functionGenerous memory capacity for up to 200 buttonsCompact size
